LED-RAINBOW-V1B

LED-RAINBOW-V1B is a SMT (surface mount) LED bar graph. It has 12 LEDs (size:3020) with different colors (red, orange, yellow, green, yellow green, blue, violet, pink, warm white, white) and 12 NPN transistors drive each single LED separately. The NPN transistors act as an on/off switch where a "high" signal applied to the control lines will turn on the LED and "low" will turn it off. Since the LEDs are driven by transistors switch, it reduces the power output needed from the driving microcontroller. The LED-RAINBOW-DEV is great for all electronics developers, students and hobbyists. It reduces set up time for connecting transistors, resistors and LEDs in a breadboard. It has a standard 14 pins 0.1"(2.54mm) header which can directly insert into a standard breadboard. You just need to connect a 5V power, Ground and LED control signals and no external component is needed.

Download Datasheet
Download Schematic

ASD-V1D

The ASD-V1D is a simple DIY kit for audio level display. You can cascade a few pieces together to make an audio spectrum display. The circuit is based on the LM3914 Dot/Bar Display Driver and uses the LED-RAINBOW bar graph as the display. 10-step Dot or Bar display mode is selectable by the user. External audio signals can be connected by 3.5mm audio jacks. Audio signal gain can be adjusted by the operational amplifier with a single potentiometer. This module can be powered by a single 5V USB power supply - this can be from any PC USB port or any USB power transformer. It works perfectly with most computers, mp3 players, mobile phones or any audio devices with a 3.5mm audio plug.

Download Datasheet
Download Schematic

OLED-160X128-DEV-V1C

The OLED-160X128-DEV-V1C is a simple OLED development module for interfacing the 160X128 OLED. The board provides an on-board 14.5V voltage boost converter circuit which allows operate from a single 3.3V supply. A 16 pin 0.1"(2.54mm) pitch header is used for the interfacing with microcontroller on a standard bread board.

Download Datasheet
Download All Related Documents
Download Sample Code

PIC-TO-ICSP-V1B

PIC-TO-ICSP-V1B is an adapter that allows you to interface the Microchip RJ-11 connector to 0.1" ICSP and 0.05" ICSP connectors. It is used to connect the Microchip MPLAB Programmers (Pickit1, Pickit2, Pickit3, ICD, ICD2, ICD3 and REAL ICE) to the ElabGuy PIC32 Development boards or to a standard bread board. Most of the Microchip PIC designs only require 5 pins for programming, therefore the PIC-TO-ICSP-V1B offers you 5 or 6 pins 0.1" ICSP connectors and 5 or 6 pins 0.05" connectors.

Download Datasheet
Download Schematic

uSD-BO-V2A

uSD-BO-V2A is a simple microSD socket breakout board. It brings all 9 pins (includes a card detect pin) of a microSD connector to standard 0.1"(2.54mm)headers for testing, prototyping and breadboard connection. The card detect LED turns on when there is a microSD card inserted. For breadboard connections, user can use the 9pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection. This module is great for LCD photo frame, MP3, data logger and more other projects.

Download Datasheet

AJ-BO-V1A

AJ-BO-V1A is a simple 3.5mm stereo audio jack breakout board. It brings all 4 pins (Tip, Ring, Sleeve and Detect) of an audio jack to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 4pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

AJ-BO-V1B

AJ-BO-V1B is a simple 3.5mm stereo audio jack breakout board. It brings all 4 pins of an 4pin audio jack to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 4pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

AP-BO-V1A

AP-BO-V1A is a simple 3.5mm 4pins stereo audio plug breakout board. It brings all 4 pins of an 4pin audio plug to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 4pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

RCA-BO-V1A

RCA-BO-V1A is a simple RCA (A/V) socket breakout board. It brings all 2 pins of a RCA socket to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 4pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

RJ11-BO-V1A

RJ11-BO-V1A is a simple RJ11 6P6C socket breakout board. (Also compatible with RJ14 and RJ25) It brings all 6 pins of a RJ11 socket to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 6pin header on the bottom for a sideways connection. User can also use the two 6pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

RJ45-BO-V1A

RJ45-BO-V1A is a simple RJ45 8P8C socket breakout board. It brings all 8 pins of a RJ45 socket to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 8pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

HDMI-AM-BO-V1A

HDMI-AM-BO-V1A is a simple HDMI Type A Male Plug breakout board. It brings all 19 pins of a HDMI A male plug to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the two 10pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

HDMI-AF-BO-V1A

HDMI-AF-BO-V1A is a simple HDMI Type A Female socket breakout board. It brings all 19 pins of a HDMI A female socket to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the two 10pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

HDMI-AF-BO-V1AS

HDMI-AF-BO-V1AS is a simple HDMI Type A Female socket breakout board. It brings all 19 pins of a HDMI A female socket to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 20pin headers on the bottom of the breakout board to mount on a breadboard.

Download Datasheet

USB-AM-BO-V1A

USB-AM-BO-V1A is a simple USB Type A male plug breakout board. It brings all 4 pins of a USB2.0 Type A connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 4pin header on the bottom for a sideways connection. User can also use the two 4pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

USB-AF-BO-V1A

USB-AF-BO-V1A is a simple USB2.0 Type A female socket breakout board. It brings all 4 pins of a USB2.0 Type A connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 5pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

USB-BF-BO-V1A

USB-BF-BO-V1A is a simple USB2.0 Type B female socket breakout board. It brings all 4 pins of a USB2.0 Type B connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 5pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

USB3-AM-BO-V1A

USB3-AM-BO-V1A is a simple USB3.0 Type A male plug breakout board. It brings all 9 pins of a USB3.0 Type A connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

USB3-AF-BO-V1A

USB3-AF-BO-V1A is a simple USB3.0 Type A female socket breakout board. It brings all 9 pins of a USB3.0 Type A connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

USB3-BF-BO-V1A

USB3-AF-BO-V1A is a simple USB3.0 Type A female socket breakout board. It brings all 9 pins of a USB3.0 Type A connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet
Download Drawing

D9-B0-V2A (Female & Male)

D9-BO-V2A is a simple DB9 connector breakout board. It is similar to the version 1A design except it added 2 mounting holes. It brings all 9 pins of a DB9 connector to screw terminal blocks and headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection. User can also use the two 5pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

D15-B0-V1A (Female & Male)

D15-BO-V1A is a simple DB15 connector breakout board. It brings all 15 pins of a DB15 connector to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection.

Download Datasheet

D25-B0-V1A (Female & Male)

D25-BO-V1A is a simple DB15 connector breakout board. It brings all 15 pins of a DB15 connector to headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection.

Download Datasheet

D15HD-B0-V1A (Female & Male)

D15HD-BO-V1A is a simple DB15HD VGA connector breakout board. It brings all 15 pins of a DB15HD connector to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the two 8pin headers on both sides of the breakout board to connect to the front end of the breadboard for a steady connection.

Download Datasheet

D15HD-B0-V1AS (Female & Male)

D15HD-BO-V1AS is a simple DB15HD VGA connector breakout board. It brings all 15 pins of a DB15HD connector to screw terminal blocks or headers for easy testing, prototyping and breadboard connection. For breadboard connections, user can use the 10pin header on the bottom for a sideways connection.

Download Datasheet
